RS318B P11 930 PSD-E WB D

Specifications Show all

Operating and Electrical

Number of products on MCB of 16 A type B	-
Input Frequency	0/50/60 Hz
Power Consumption	11 W
Line Frequency	0/50/60 Hz
Input Voltage	220 to 240 V
Inrush current	0.056 A
Power Factor (Fraction)	0.9

Approval and Application

Ingress protection code	IP20  [Finger-protected]
Protection class IEC	Safety class II
CE mark	-
Flammability mark	-
Mech. impact protection code	IK03  [0.35 J reinforced]

Product Data

Order product name	RS318B P11 930 PSD-E WB D
Numerator - Quantity Per Pack	1
Full product name	RS318B P11 930 PSD-E WB D
Order code	911401506432
Numerator - Packs per outer box	16
Material number (12NC)	911401506432

Controls and Dimming

Dimmable	Yes
Control interface	DALI

General Information

Light source engine type	LED
Value ladder	Performance

Mechanical and Housing

Overall width	85 mm
Housing Color	Aluminum and gray
Optical cover/lens material	Polycarbonate
Optical cover/lens finish	Clear
Overall length	93 mm
Overall diameter	85 mm
Housing Material	Aluminum die-cast
Overall height	93 mm
Dimensions (Height x Width x Depth)	93 x 85 x 93 mm

Initial Performance (IEC Compliant)

Initial chromaticity	-
Power consumption tolerance	+/-10%
Luminous flux tolerance	+/-10%

Temperature

Ambient temperature range

-20 to +40 °C

Light Technical

Correlated Color Temperature (Nom)	3000 K
Luminous Efficacy (rated) (Nom)	101 lm/W
Optical cover/lens type	-
Luminous Flux	770 lumen
Light source color	930 warm white
Color rendering index (CRI)	>90
