    • The new generation of energy saving and affordable T5 Mains tube lighting

      MASTER LEDtube 1200mm 13W865 G5 I
      LED
      MASTER LEDtube 1200mm 13W865 G5 I
      Essential LED tubes T5 Mains

      MASTER LEDtube 1200mm 13W865 G5 I

      Downloads

      Spec Sheet
      Size:138.4 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Input Frequency
    50 to 60 Hz
    Power Consumption
    13 W
    Warm-up time to 60% light
    0.5 s
    Line Frequency
    50 to 60 Hz
    Power Factor (Fraction)
    0.9
    Starting Time (Nom)
    0.5 s
    Voltage (Nom)
    33 V
    Approval and Application
    Approval Marks
    RoHS compliance
    KEMA Keur certificate
    CE marking
    EU RoHS compliant
    Yes
    Energy Consumption kWh/1000 h
    15 kWh
    Suitable For Accent Lighting
    No
    Energy Saving Product
    Yes
    Product Data
    Order product name
    MASTER LEDtube 1200mm 13W865 G5 I
    Numerator - Quantity Per Pack
    1
    Full product code
    694793910875600
    Full product name
    MASTER LEDtube 1200mm 13W865 G5 I
    Order code
    929001131210
    Numerator - Packs per outer box
    20
    EAN/UPC - Case
    6947939108763
    Material number (12NC)
    929001131210
    Controls and Dimming
    Dimmable
    No
    General Information
    Nominal lifetime
    40,000 hour(s)
    Lighting Technology
    LED
    Cap-Base
    G5  [G5]
    Switching Cycle
    50,000
    Mechanical and Housing
    Product Length
    1,200 mm
    Bulb Shape
    Tube, double-ended
    Temperature
    T-Case Maximum (Nom)
    50 °C
    Ambient temperature range
    -20 °C to 45 °C
    Light Technical
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Beam Angle (Nom)
    160 degree(s)
    Color Consistency
    <6
    Correlated Color Temperature (Nom)
    6500 K
    Color Designation
    Cool Daylight
    Luminous Efficacy (rated) (Nom)
    123.00 lm/W
    Luminous Flux
    1,600 lumen
    Color rendering index (CRI)
    83
    Color Code
    865  [CCT of 6500K]

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    G5
    G5
    G5
    G5
    Photometrics
    General uniform lighting - MASTER LEDtube 1200mm 13W865 G5 I
    General uniform lighting - MASTER LEDtube 1200mm 13W865 G5 I
    Spectral Power Distribution Colour - MASTER LEDtube 1200mm 13W865 G5 I
    Spectral Power Distribution Colour - MASTER LEDtube 1200mm 13W865 G5 I
    Light Distribution Diagram - MASTER LEDtube 1200mm 13W865 G5 I
    Light Distribution Diagram - MASTER LEDtube 1200mm 13W865 G5 I
    Downloads
    Leaflets
    Green Data
    Visuals
    Software Plugins
    • IES IES File - MASTER LEDtube 1200mm 13W865 G5 I IES 4.1 kB
